T-splitter, M12, male, straight, 4+FE, L-coded, M12, female, straight, 4+FE, L-coded, M12, female, straight, 4+FE, L-coded, POWER
Product description
Product type: Splitter
Application: POWER
Item description: PL-TM12-S5-2K5
Item-No.: 8075819
Inquiry
Minimum quantity:10 pcs
Packaging unit:1 pcs
Quantity: Your entry was adjusted according to the minimum quantity and packaging unit.
Certifications
![CE CE](https://www.escha.net/media/storage/CE_logo.jpg_preview300.jpg)
![UKCA UKCA](https://www.escha.net/media/storage/UKCA.jpg_preview300.jpg)
![SIHI E SIHI E](https://www.escha.net/media/storage/SIHI_electrotechnical_expertise.jpg_preview300.jpg)
![UL Listed UL Listed](https://www.escha.net/media/storage/UL_Listed_1.jpg_preview300.jpg)
![CHINA RoHS CHINA RoHS](https://www.escha.net/media/storage/China_RoHS.jpg_preview300.jpg)
Product details
Technical data | Exit 0 | Exit 1 | Exit 2 |
---|---|---|---|
Ambient temperature product | -30°C...+90°C | ||
Coding of | L | L | L |
Connector | Male, M12 | Female, M12 | Female, M12 |
Contact material | Metal, CuZn, gold-plated | Metal, CuZn, gold-plated | Metal, CuZn, gold-plated |
Contact-carrier material | Plastic, PA, BK | Plastic, PA, BK | Plastic, PA, BK |
Coupling nut material | Metal, CuZn, nickel-plated | Metal, CuZn, nickel-plated | Metal, CuZn, nickel-plated |
Current load (at 25°C) (UL) | 12 A | 12 A | 12 A |
Current load (at 40°C) | 16 A | 16 A | 16 A |
Degree of pollution | 3 | ||
Degree of protection (mounted) | IP65, IP67, IP68 | ||
Grip body material | Plastic, TPU, BK | ||
Insulation resistance |
|
||
Mechanical life-cycle | >100 mating cycles | ||
Number of pins | 4+FE | 4+FE | 4+FE |
Rated voltage |
|
|
|
Sealing (female) material | FPM/FKM | ||
Standards | IEC 61076-2-111 |
