Field-wireable, RJ45, male, straight, 8 poles, insulation displacement contact, shielded, 50V 1A
Product description
Product type: Field-wireable
Application: Industrial Ethernet
Item description: IE-RJ45SCS8
Item-No.: 8065955
Inquiry
Stock: Currently out of stock.
Packaging unit: 1 pcs
Minimum quantity: 10 pcs
Quantity: Your entry was adjusted according to the minimum quantity and packaging unit. pcs
Certifications
Product details
| Technical data | |
|---|---|
| Allocation | Industrial, T568B, T568A |
| Ambient temperature product | -40°C...+85°C |
| Cable outlet | 5,5...10,5 mm |
| Coding | A |
| Connecting cross-section | AWG27/7 – AWG22/7 (0,46-0,76 mm) | AWG26/1 – AWG22/1 (0,4-0,64 mm) |
| Connecting type | Insulation displacement contact |
| Connector | Male, straight, RJ45 |
| Contact material | Metal, CuSn, gold-plated |
| Contact-carrier material | Plastic, PA UL94-V0, BK |
| Current load per pin (at 40°C) | 1 A |
| Degree of pollution | 1 |
| Degree of protection (mounted) | IP20 |
| Fire prevention according to | DIN EN 45545-2 HL1-3 |
| Insulation resistance |
|
| Material of shielding housing | Zinc die-cast |
| Mechanical life-cycle | >750 mating cycles |
| Number of pins | 8 |
| Rated voltage |
|
| Shielding | With shielding |
| Shock & vibration | Class 1, Category B (DIN EN 61373) |
| Standards | IEC 60603-7-51 |
| Temperature range | Tx (-40°C...+90°C) |
| Transmission features | Cat6A |
