Receptacle, M12, female, angled, 4 poles, back wall-mounting, print contact
Product description
Product type: Receptacle
Application: Sensor/actuator
Item description: EC-WFKF4-P/12/S3540
Item-No.: 8050274
Inquiry
Minimum quantity:10 pcs
Packaging unit:10 pcs
Quantity: Your entry was adjusted according to the minimum quantity and packaging unit.
Certifications
![CE CE](https://www.escha.net/media/storage/CE_logo.jpg_preview300.jpg)
![UKCA UKCA](https://www.escha.net/media/storage/UKCA.jpg_preview300.jpg)
![SIHI E SIHI E](https://www.escha.net/media/storage/SIHI_electrotechnical_expertise.jpg_preview300.jpg)
![CHINA RoHS CHINA RoHS](https://www.escha.net/media/storage/China_RoHS.jpg_preview300.jpg)
![rail approved rail approved](https://www.escha.net/media/storage/Rail_Approved_K_logo.jpg_preview300.jpg)
Product details
Technical data | |
---|---|
Ambient temperature product | -30°C...+90°C |
Coding | A |
Connecting type | Print contact |
Connector | Female, angled, M12 |
Contact material | Metal, CuZn, gold-plated |
Contact-carrier material | Plastic, TPU, BK |
Current load per pin (at 40°C) | 4 A |
Degree of pollution | 3 |
Degree of protection (mounted) | IP65, IP67, IP68 |
Fire prevention according to | DIN EN 45545-2 HL1-3 |
Insulation resistance |
|
Material of external sealing | NBR |
Mechanical life-cycle | >100 mating cycles |
Mounting direction | Back wall-mounting (incl. Fixing screw) |
Number of pins | 4 |
Rated voltage |
|
Receptacle housing material | Metal, CuZn, nickel-plated |
Sealing (female) material | FPM/FKM |
Shock & vibration | Class 1, Category B (DIN EN 61373) |
Standards | IEC 61076-2-101 |
Temperature range | Tx (-40°C...+90°C) |
Wall thickness area (Δh) | 2,5...4 mm |
