I/O-junctions, 8 ports, front contact, M12, female, 5 poles
Product description
Product type: Passive junction
Item description: 8MB12-5P4-K-SK
Item-No.: 8018198
Inquiry
Stock: Currently out of stock.
Packaging unit: 1 pcs
Minimum quantity: 10 pcs
Quantity: Your entry was adjusted according to the minimum quantity and packaging unit. pcs
Certifications
Product details
| Technical data | |
|---|---|
| Ambient temperature product | -30°C...+90°C |
| Circuit logic | Pnp |
| Coding | A |
| Connecting type | Hood version |
| Contact material | Metal, CuZn, gold-plated |
| Contact-carrier material | Plastic, PBT, BK |
| Current load per pin (at 40°C) | 2 A |
| Degree of pollution | 3 |
| Degree of protection (mounted) | IP65, IP67 |
| Housing material | Plastic, PBT, GY |
| I/O-junction | 8-way, M12 |
| I/O-slot | Female, M12 |
| Insulation resistance |
|
| Mechanical life-cycle | >50 mating cycles |
| Number of I/O-slots | 8 |
| Number of pins | 5 |
| Operating voltage-indicator | LED GN |
| Rated voltage |
|
| Resistance | 5 mΩ |
| Signal status-indicator | LED YE |
| Thread insert material | Metal, CuZn |
| Total current load | 12 A |
