Field-wireable, M23, female, straight, 19 poles, soldering contact, 125V
Product description
Product type: Field-wireable
Application: Sensor/actuator
Item description: MKCC19L
Item-No.: 8013696
Inquiry
Stock: 37 pcs
Packaging unit: 1 pcs
Minimum quantity:
• Stock sale: min. 1 pcs
• Production: min. 10 pcs
Quantity: Your entry was adjusted according to the minimum quantity and packaging unit. pcs
Certifications
Product details
| Technical data | |
|---|---|
| Ambient temperature product | -40°C...+125°C |
| Cable outlet | 10...14 mm |
| Coding | A |
| Connecting cross-section | Contacts 6,12,19 0,75…1 mm² | all other 0,5…0,75 mm² |
| Connecting type | Soldering contact |
| Connector | Female, straight, M23 |
| Contact material | Metal, CuZn, gold-plated |
| Contact-carrier material | Plastic, PBT, GY |
| Coupling nut material | Metal, CuZn, nickel-plated |
| Current load power |
|
| Current load signal |
|
| Degree of pollution | 3 |
| Grip body material | Metal, CuZn, nickel-plated, silver-plated |
| Insulation resistance |
|
| Mechanical life-cycle | >100 mating cycles |
| Number of pins | 19 |
| Rated voltage |
|
| Sealing (female) material | Plastic, NBR |
| Standards | IEC 61076-2-101 |
