Panel connector, Ø8mm snap, male, straight, 3 poles, soldering contact
Product description
Product type: Panel connector
Item description: ESGP3L
Item-No.: 8008744
Inquiry
Minimum quantity:10 pcs
Packaging unit:1 pcs
Quantity: Your entry was adjusted according to the minimum quantity and packaging unit.
Certifications
![CE CE](https://www.escha.net/media/storage/CE_logo.jpg_preview300.jpg)
![UKCA UKCA](https://www.escha.net/media/storage/UKCA.jpg_preview300.jpg)
![CHINA RoHS CHINA RoHS](https://www.escha.net/media/storage/China_RoHS.jpg_preview300.jpg)
Product details
Technical data | |
---|---|
Ambient temperature product | -30°C...+90°C |
Connecting type | Soldering contact |
Connector | Male, M8/Ø8mm snap |
Contact material | Metal, CuZn, gold-plated |
Current load per pin (at 40°C) | 4 A |
Degree of pollution | 3/2 |
Degree of protection (mounted) | IP65, IP67 |
Housing material | Metal, CuZn, nickel-plated |
Insulation resistance |
|
Mechanical life-cycle | >100 mating cycles |
Number of pins | 3 |
Rated voltage |
|
Standards | IEC 61076-2-104 |
